Recirculation valves

Circulation valve with microswitch (IP55) and cable1000 mm for high-pressure pumps of all manufacturers. Inlet 3/8" female thread Outlet 3/8" female thread Bypass 3/8" female thread Pressure gauge 1/4" female thread Max. 220 bar / 90 °CPressure switch is a changeover switch. Can be used as a normally closed or normally open contact.

VB350 StandardInlet 3/8" female threadOutlet 3/8" female threadBypass 1/2" female threadPressure gauge 1/4" IGMax. 350 bar / 90°C / 40 l/min

Leuco MT-LT / CAT 5CP

AR Series RC

AR Series RK; Comet Series FW

IP 50-44-47-60-63, SpeckNP16, Annovi

VB9 StandardInlet 3/8" female threadOutlet 3/8" female threadBypass 3/8" female threadPressure gauge 1/4" IGMax. 220 bar / 90°C / 30 l/min

E:1/2 "IG A:3/8 "AG BY-PASS:1/2 "IG

Recirculation valve for motor pump Comet FW series with total/stop function

Inlet 1/2" AG. Outlet 3/8" AG.Recirculation valve with banjo bolt. Banjo connection. X: 4.5 mm. Y: 53-64 mm. Suitable for AR series XM, RR, JK and RK. Max. 250 bar / 45 °C (*60 °C)

Inlet 3/4" female thread. Outlet 3/8" AG. Recirculation valve with banjo bolt. Banjo connection. X: 8.5 mm. Y: 68-77 mm. Suitable for AR series XW. Max. 250 bar / 45 °C (*60 °C)

Inlet 1/2" AG. Outlet 3/8" AG. Recirculation valve with banjo bolt. Chemical injector ( 2.1 mm) spout 8 mm. Banjo connection. X: 4.5 mm. Y: 53-64 mm. Suitable for AR series XM, JK and RK. Max. 250 bar / 45 °C (*60 °C)

Pressure range from 200 - 700 barWater temperature up to 60°Calso up to max. 85°C for short periodsMillimetre-precise, simple stepless adjustmentSimple replacement of the seal setVery stable and compact designMax. Max. solids size: 50?mpH water: 6.5 8.0Pump pressure valve pressure: <+/- 15 bar
