Foam applications and foam cleaning

Injector made of chemical-resistant stainless steel 1.4305 / AISI 304 with dosing valve ST-161, compressed air connection and wall bracket.Inlet: 1/2" female threadOutlet 1/2 "IG.Air connection: 1/4 "AGChemical suction: Nozzle 9 mmMax. 350 bar / 90 °CFor the ST-160.2 foam injector, a foam lance that does not draw in air itself is absolutely necessary to generate the foam. The air volume required for foaming is supplied through an additional connection on the injector. The use of a foam gun with large cross-sections such as ST-2720, ST-2725, ST-3100 or ST-3300 with suitable lances and foam hoses (PUReClean365+) is recommended.The injector is particularly suitable for low or medium pressure from 5 bar water inlet pressure and produces an excellent foam pattern with an appropriate compressed air supply.

Injector ST-162 with compressed air connectionInlet: 3/8" female threadOutlet: 1/2" female threadSuction: Nozzle 9 mm.Compressed air connection: 9 mm nozzleChemical dosing is regulated by 10 interchangeable dosing inserts (0.5 - 2.0 mm).Max. 350 bar / 100 °C

easyfoam365+ bypass injectors ST-167 without compressed air moduleInlet: 1/2 "IGOutlet: 1/2 "IGChemical connection: 9 mm spoutChemical dosing is regulated by 10 interchangeable dosing inserts (0.5 - 2.0 mm).Max. 350 bar / 100 °C

easyfoam365+ bypass injectors ST-167 without compressed air moduleInlet: 1/2 "IGOutlet: 1/2 "IGChemical connection: Dosing valve ST-161 with 9 mm spoutMax. 350 bar / 100 °C

Injector ST-168 with compressed air connectionInlet: 1/2" female threadOutlet: 1/2" female threadSuction: 2 x spout 9 mm.Chemical dosing is regulated by 10 interchangeable dosing inserts (0.5 - 2.0 mm).Max. 350 bar / 100 °C

Injector ST-168 with compressed air connection Inlet: 1/2" female thread Outlet: 1/2" female thread Suction: 2 x spout 9 mm. Chemical dosing is regulated by the dosing valve ST-161. 350 bar / 100 °C max.

Areas of application:Disinfection, humidification / cooling, odour neutralisation, dust suppressionVehicle preparation, decontamination, pest controlAdvantages:System provides a safe and cost-effective method for neutralising odours and disinfection.Uniform spray pattern (mist)No inhalation of the disinfectant solution - Increased operator safety, as the area to be disinfected does not need to be entered during the process. Compressed air connection via plug nipple

Drill hole

for retrofitting easyfoam365+ injectorsGrommet 9 mmM14 AG thread with O-ring seal.Sealing ring: FKMSuitable for injector series:ST-160, 160.2, 160.3, ST-167, ST-168

njector ST-164 without compressed air connectionInlet: 3/8" female threadOutlet: 1/2" female threadNozzle size selectableSuction: 2 x nozzle 9 mmChemical dosing is regulated by 2 x 10 interchangeable dosing inserts (0.5 - 2.0 mm)Max. 350 bar / 100°C

Injector ST-164 with compressed air connectionInlet: 3/8" female threadOutlet: 1/2" female threadNozzle size selectableSuction: 2 x nozzle 9 mmCompressed air module: 1/4 "AGChemical dosing is regulated by the dosing valve ST-161Max. 350 bar / 100°C

Injector ST-164 with compressed air connectionInlet: 3/8" female threadOutlet: 1/2" female threadNozzle size selectableSuction: 2 x nozzle 9 mmCompressed air module: 1/4 "AGChemical dosing is regulated by the dosing valve ST-1612x10 interchangeable dosing inserts (0.5 mm - 2.0 mm)Max. 350 bar / 100°C

Technical specificationsWater pressure 2.5 - 6 bar (for maximum accuracy 3 - 4 bar)Output 5.5 l/minConnection: Tap connectorMixing ratioThe dosing head has 5 settings and OFF.ApplicationsFor the use of acidic and alkaline cleaners as well as soaps, disinfectants, degreasers and descaling agents for a wide range of applications." Food industry and commercial kitchens" Sanitary facilities and swimming pools" Cleaning lorries, cars and other vehicles" Car workshops and petrol stations" Workshops and production plantsCleaning foam is produced using foam injectors that are connected directly to the water pipe. The cleaning agent and air are sucked in by the water pressure, both are swirled together to form a foam and sprayed using a foam attachment or a spray head. At the same time, the cleaning agent can be diluted specifically and automatically by a dosing device in order to select the correct dosage for each application.Properties" Good chemical resistance to alkaline and acidic products." Produces a strong, long-lasting foam." Automatic dosing of chemicals." Dosing head made of polymer plastic with stainless steel screws." 5-way adjustable dosing." Non-return valve built into the gun handle." Gun can be removed via quick-release coupling for rinsing with water." Easy filling due to wide opening." Only works with water line pressure." Suitable for all commercially available water couplings.

Material: Stainless steel / plastic.At least 70 bar when operated with an easyfoam365+ injector.At least 30 bar for operation with water / foam concentrate premix.Max. 250 bar / 20 - 60 l/min / 100 °CInlet: 1/2 "IGThe foamblaster ST-76 is suitable for foam applications without the supply of compressed air in industry, agriculture, municipal or fire extinguishing technology.Suitable injector nozzles with a diameter of up to 2.8 mm for large volume flows are available for all easyfoam365+ injectors ST-160, ST-164, ST-166 and ST-167 made of stainless steel.

ST-60.1 BrassInjector without dosingNozzle size 1.6Inlet 3/8" AGOutlet 3/8" female threadMax. 250 bar / 60°CCan also be used as a low-pressure injector:Min. 2 bar - max. 10 barFlow rate at 2 bar approx. 150 l/hAdmixture approx. 0 - 11.5%

ST-60.1 BrassInjector without dosingNozzle size 1.6Inlet 3/8" AGOutlet 3/8" female threadMax. 250 bar / 60°CCan also be used as a low-pressure injector:Min. 2 bar - max. 10 barFlow rate at 2 bar approx. 150 l/hAdmixture approx. 0 - 11.5%

Foam injector lance with dosage and bottle.Connection: KW-Profi plug-in nippleNozzle size 1.25Tank capacity 1 litreMax. 300 bar / 80°COur easyfoamer ST-73.1 foam injector lance ensures optimum air/detergentcleaning agent mixture and thus for an optimum foaming result.You can rely on:" an injector made entirely of stainless steel and corrosion-resistant" special chemical resistance" 5 defined dosing positions" 1 litre and 2 litre container" a vertical or horizontal spray pattern" a registered patent

Foam injector lance with dosing and bottle Connection: KW-Profi plug-in nipple Nozzle size 1.25 Tank capacity 1 litre Max. 300 bar / 80°C Our easyfoamer ST-73.1 foam injector lance ensures optimum air/detergent mixing and therefore optimum foaming results. You can rely on: " an injector made entirely of stainless steel and corrosion-resistant " special chemical resistance " 5 defined dosing positions " 1 l and 2 l tanks " a vertical or horizontal spray pattern " a registered patent

easyfoamer ST-73.1 Foam injector lancesFoam injector lance with dosage and bottleConnection: 1/4 "IGNozzle size 2.10Tank capacity 2 litresMax. 300 bar / 80°COur easyfoamer ST-73.1 foam injector lance ensures optimum air/detergentcleaning agent mixture and thus for an optimum foaming result.You can rely on:" an injector made entirely of stainless steel and corrosion-resistant" special chemical resistance" 5 defined dosing positions" 1 litre and 2 litre container" a vertical or horizontal spray pattern" a registered patent

Foam injector lance with dosage and bottleConnection: 1/4 "IGNozzle size 1.50Tank capacity 2 litresMax. 300 bar / 80°COur easyfoamer ST-73.2 foam injector lance ensures optimum air/detergentcleaning agent mixture and thus for an optimum foaming result.You can rely on:" particularly suitable for high flow rates" without foam pad" injector made entirely of stainless steel and corrosion-resistant" special chemical resistance" 5 defined dosing positions" 2 litre container" one vertical or horizontal spray pattern

Lightweight: The foam nozzle weighs less than 43 grams Nozzle: 50° 200 Max. 45 bar / 60°C Input: ST-3100 connector Private label possible (HACCP / possible colours: white, yellow, red, blue and green) please contact us
